ULE-185U Rev.H
18.5-inch HDTV Full HD professional monitor
Discontinued Product
The ULE-185U is a professional multi-purpose Full HD monitor with 3G/HD-SDI and HDMI interface. ULE-185U is ideal for PC applications, or HD video monitoring. With a VESA interface it can be easily racked, wall-mounted or used as a desktop.
- Full HD 3G Multi-format LED Monitor
- LED backlight to extend the lifetime and save power
- Non-glare surface coating
- SD/HD/3G-SDI(level A) is supported
- PC(VGA) and HDMI inputs
- Wireless remote control
- PIP/PBP multi display function
- Anti-reflection coating protection cover
| General Features ULE-185U REV.H | ||
| Display | Screen Size | H1366×V768 |
| Pixel Pitch | 0.300×0.300mm | |
| Brightness | 250cd/m² | |
| Contrast Ratio | 1000:1 | |
| Aspect Ratio | 16:9 | |
| Viewing Angle(H/V) | 170°(H/V) | |
| Display Color | 16.7 million | |
| Response Time | 14msec. | |
| Video System | NTSC/PAL | |
| Panel Life Time(hours) | 30,000 hours | |
| Interface | Video In/Out(BNC Type) | 2/2 |
| VGA In(15Pin D-Sub) | 1 | |
| HDMI In | 1 | |
| SDI In/Out | 1/1 | |
| Audio In(RCA Type) | 2 | |
| PC Stereo In | 1 | |
| Special Features | Built in Speakers | Yes(1W×2) |
| Remote Control | Yes | |
| Filter Type | 3D Comb filter | |
| Deinterlacing | Yes | |
| Trigger Source Switching | Yes | |
| Noise reduction | Yes | |
| Auto source sequencing | Yes | |
| Multilingual Language | Eng, Spa, Fre, Ger, Ita | |
| Dimension | Outline Dimension(with Stand) | 17.64”×11.72”×3.58” |
| Cabinet | Cabinet Material | Electro-Galvanized Steel |
| Power | Electrical Ratings | DC 12V |
| Circumstance | OperatingTemperature | 0℃~50℃ |
| Storage Temperature | -20℃~60℃ | |
| Mounts | VESA Mount Size |
100×100mm |
| Ceiling Mount | CMK-01 | |
| Wall Mount | WB-5, 10, 30, 31 | |
| RackMount | RMK-08 | |
